Q3


Q3
SERIES

PV Panel: 25-45W, Luminous Flux: 1600-3000lm, LifePO4 Battery: 89.6-153.6Wh

                                SELECT Q3
Q5


Q5
SERIES

PV Panel: 38-48W, Luminous Flux: 3000-5000lm, LifePO4 Battery: 230.4-307.2Wh

                                SELECT Q5
Q6


Q6
SERIES

PV Panel: 65 - 130W, Luminous Flux: 6400 - 11200lm, LifePO4 Battery: 537.6 - 921.6Wh

                                SELECT Q6
Q7


Q7
SERIES

PV Panel: 180-245W, Luminous Flux: 11200-13600lm, LifePO4 Battery: 921.6-1280Wh

                                SELECT Q7

Q3 Series All In One Solar Street Lights

The Q3 series (all in one solar street light) adopts a robust die-cast aluminum housing, which does not fear severe cold and heat. It is equipped with a high-sensitivity microwave sensor, which makes its work more energy-saving and efficient.
The Q3 Series (all in one solar street light) covers LED power 10W/12W/15W/20W (luminous flux 1600 - 3200lm), which is more suitable for small areas such as residential areas, gardens, parks, and paths.

Main Features:
Integrated design and modular structure
No wiring, easy to install and simple to maintain
Solar Panel 25 - 45W, LED Power 10 - 20W, Luminous Flux 1600 - 3200lm
Robust die-cast aluminum alloy housing
Up to 20% conversion rate MONO solar panel
Over 2000 cycles LiFePO4 lithium battery
8-10 meters High-sensitivity microwave sensor
Bridgelux LED chip 160lm/w
Recommended installation height 4 - 6 meters

Model

PV Panel

LED Power

Luminous Flux

LiFePO4 Battery

QKAT0363-AIO2510

25W 5V MONO

10W

1600lm

89.6Wh (28AH) 3.2V

QKAT0363-AIO3012

30W 5V MONO

12W

1920lm

96Wh (30AH) 3.2V

QKAT0363-AIO4015

40W 5V MONO

15W

2400lm

115.2Wh (36AH) 3.2V

QKAT0363-AIO4520

45W 5V MONO

20W

3200lm

153.6Wh (48AH) 3.2V

Q3 Series Specifications
Q3
