Q3


Q3
SERIES

PV Panel: 25-45W, Luminous Flux: 1600-3000lm, LifePO4 Battery: 89.6-153.6Wh

                                SELECT Q3
Q5


Q5
SERIES

PV Panel: 38-48W, Luminous Flux: 3000-5000lm, LifePO4 Battery: 230.4-307.2Wh

                                SELECT Q5
Q6


Q6
SERIES

PV Panel: 65 - 130W, Luminous Flux: 6400 - 11200lm, LifePO4 Battery: 537.6 - 921.6Wh

                                SELECT Q6
Q7


Q7
SERIES

PV Panel: 180-245W, Luminous Flux: 11200-13600lm, LifePO4 Battery: 921.6-1280Wh

                                SELECT Q7

Q6 Series All In One Solar Street Lights

The Q6 Series (compact solar street light) makes up for the medium-sized solar street lights with PV panel of 65-130W and LED actual power of 40-70W. Compared with other series of the same size, it has increased battery capacity and LED power, but the cost is well controlled.
The Q6 (compact solar street light) Series covers LED power 40W/50W/65W/70W (luminous flux 6400 - 11200lm), which is suitable for medium and large areas such as main roads parking lots, and stadiums.

Main Features:
Integrated design and modular structure
No wiring, easy to install and simple to maintain
Solar Panel 65 - 130W, LED Power 40 - 70W, Luminous Flux 6400 - 11200lm
Slim extruding aluminum alloy frame
Up to 20% conversion rate MONO solar panel
Over 2000 cycles LiFePO4 lithium battery
8-10 meters High-sensitivity microwave sensor
Precise timing control mode
Bridgelux LED chip 160lm/w
Adjustable angle bracket
Recommended installation height 7 - 10 meters

Model

PV Panel

LED Power

Luminous Flux

LiFePO4 Battery

QKAT0911-AIO6540

65W 18V MONO

40W

6400lm

537.6Wh (42AH) 12.8V

QKAT0911-AIO8850

88W 18V MONO

50W

8000lm

691.2Wh (54AH) 12.8V

QKAT0911-AIO10065

100W 18V MONO

65W

10400lm

768Wh (60AH) 12.8V

QKAT0911-AIO13070

130W 16.5V MONO

70W

11200lm

921.6Wh (72AH) 12.8V

Q6 Series Specifications
Q6
