Q3


Q3
SERIES

PV Panel: 25-45W, Luminous Flux: 1600-3000lm, LifePO4 Battery: 89.6-153.6Wh

                                SELECT Q3
Q5


Q5
SERIES

PV Panel: 38-48W, Luminous Flux: 3000-5000lm, LifePO4 Battery: 230.4-307.2Wh

                                SELECT Q5
Q6


Q6
SERIES

PV Panel: 65 - 130W, Luminous Flux: 6400 - 11200lm, LifePO4 Battery: 537.6 - 921.6Wh

                                SELECT Q6
Q7


Q7
SERIES

PV Panel: 180-245W, Luminous Flux: 11200-13600lm, LifePO4 Battery: 921.6-1280Wh

                                SELECT Q7

Q5 Series All In One Solar Street Lights


The Q5 Series (integrated solar street light) adopts high-luminous Bridge LED chips up to 200lm/W, which can not only release more luminous flux through a smaller lamp module but also optimize the internal structure of the product.
This series-based Q3 Series (integrated solar street light) increases battery capacity to meet the needs for a longer lighting time. An adjustable bracket can ensure lighting angle and improve sun energy-converted efficiency.
The Q5 Series (integrated solar street light) covers LED power 15W/25W (luminous flux 3000 - 5000lm), which is suitable for small areas such as school campuses, branch roads, subsidiary ways and parks.

Main Features:
Integrated design and modular structure
No wiring, easy to install and simple to maintain
Solar Panel 38 - 48, LED Power 15 - 25W, Luminous Flux 3000 - 5000lm
Robust die-cast aluminum alloy housing
Up to 20% conversion rate MONO solar panel
Over 2000 cycles LiFePO4 lithium battery
Precise timing control mode
Bridgelux LED high-brightness chip 200lm/w
Adjustable angle bracket
Recommended installation height 5 - 7 meters




Model

PV Panel

LED Power

Luminous Flux

LiFePO4 Battery

QKAT0310-AIO3815

38W 16V MONO

15W

3000lm

230.4Wh (18AH) 12.8V

QKAT0310-AIO4825

48W 16V MONO

25W

5000lm

307.2Wh (24AH) 12.8V

Q5 Series Specifications
Q5
